Avdel 7287 - Monobolt Rivet Gun / Monobolt Tool

Breakstem and Lock-bolt Tooling by Avdel

Avdel 7287 Monobolt Tool

Avdel's 7287 Monobolt Rivet Gun / Tool is able to place heavy-duty rivets with just one press of the trigger. With an extended stroke and a quick cycle time the Avdel 7287 Monobolt Tool combines speed and power which make it the perfect Avdel tool for batch- and line-production use.

Avdel 7287 Monobolt Tool Specs

Specifications:

  • 3m long hose
  • Cycle time of 1.7 secs
  • Extended stroke of 29mm
  • Noise level <75dB(A)
  • Places many of the larger rivets in the Avdel range including the 14mm Avseal II
  • Places the new 3/8" Monobolt
  • Pull force 34KN at 5.5bar
  • Push off force 8.5KN at 5.5bar
  • Vibration - Less than 2.5m/s2
  • Weighs under 2.5kg

Avdel 7287 Monobolt Tool Benefits

Benefits:

  • Can pull a wide range of rivets reducing the number of tools needed
  • Can pull large rivets in a single stroke
  • Light to reduce operator fatigue
  • Long hose to give line side flexibility
  • Quick cycle time 40% less than many rival tools

Avdel 7287 Monobolt Tool Placing Capabilities

Call us at (866)748-3876 if you have questions about placing capabilities for the Avdel 7287 Monobolt Tool.

Placing Capabilities
Fastener Brand Size nG4 71255 7220 7287 734
Avbolt
  • 4.8 (3/16")
  • 6.4 (1/4")
  • 8.0 (5/16")
  • 10.0 (3/8")
  • 16.0 (5/8")
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • supported
  • supported
  • supported
  • not supported
  • not supported
  • supported
  • supported
  • supported
  • not supported
  • not supported
  • not supported
  • not supported
  • supported
  • supported
  • supported
Avdelok
  • 4.8 (3/16")
  • 6.4 (1/4")
  • 8.0 (5/16")
  • 9.6 (3/8")
  • supported
  • supported
  • not supported
  • not supported
  • supported
  • supported
  • not supported
  • not supported
  • supported
  • supported
  • supported
  • supported
  • supported
  • supported
  • supported
  • supported
  • not supported
  • not supported
  • not supported
  • supported
Avdelok LD
  • 12.7 (1/2")
  • 15.9 (5/8")
  • 19.1 (3/4")
  • 22.2 (7/8")
  • 25.4 (1")
  • 28.6 (1 1/8")
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • not supported
  • supported
  • supported
  • supported
  • supported
  • supported
  • supported
Avtainer
  • 10.0 (3/8")
  • supported
  • not supported
  • not supported
  • supported
  • not supported
Maxlok
  • 4.8 (3/16")
  • 6.4 (1/4")
  • supported
  • supported
  • supported
  • supported*
  • not supported
  • not supported
  • supported
  • supported
  • not supported
  • not supported
  • * = Support for Aluminum only
